2.2

Function keys

Key Description
ON/OFF
MENU
BACK
OK
HOLD
UP
DOWN
RIGHT
LEFT
2.3

Display (measurement screen)

1. Date & time
2. Battery charge
3. Measuring unit
4. Frequency range
5. Parameter
6. HOLD on/off
7. Measurement value
8. Max value
9. ISO group
10. Vibration severity zone
Function
- Turn device on/off
- Open main menu
- Cancel, return, reset max. value
- Confirm
- Hold current measurement value
- Menu up
- Menu down
- Menu right
- Menu left
Fig. 2 Measurement screen
© PCE Instruments
18
