Specifications

ENGINE
Briggs & Stratton
Model
Displacement
Electrical System
Oil Capacity
Spark Plug Gap
Spark Plug Torque
Model
Displacement
Electrical System
Oil Capacity
Spark Plug Gap
Spark Plug Torque
Model
Displacement
Electrical System
Oil Capacity
Spark Plug Gap
Spark Plug Torque
Model
Displacement
Electrical System
Oil Capacity
Spark Plug Gap
Spark Plug Torque
Power Ratings
The gross power rating for individual gasoline engine models is labeled in accordance with SAE (Society of Automotive
Engineers) code J1940 Small Engine Power & Torque Rating Procedure, and is rated in accordance with SAE J1995.
Torque values are derived at 2600 RPM for those engines with "rpm" called out on the label and 3060 RPM for all others;
horsepower values are derived at 3600 RPM. The gross power curves can be viewed at www.BRIGGSandSTRATTON.
COM. Net power values are taken with exhaust and air cleaner installed whereas gross power values are collected
without these attachments. Actual gross engine power will be higher than net engine power and is affected by, among
other things, ambient operating conditions and engine-to-engine variability. Given the wide array of products on which
engines are placed, the gasoline engine may not develop the rated gross power when used in a given piece of power
equipment. This difference is due to a variety of factors including, but not limited to, the variety of engine components
(air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions
(temperature, humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs &
Stratton may substitute an engine of higher rated power for this engine.
Parts and Accessories
Contact an authorized dealer for details.
30
Intek Series 4175 OHV
TM
500 cc (30,5 cu in.)
Battery: 12 Volt, 190 CCA
Alternator: 9 amp
1,4 L (48 oz)
0,76 mm (0.030 in.)
20 Nm (180 in-lbs)
Intek Series 7180 OHV
TM
656 cc (40,03 cu in.)
Battery: 12 Volt, 190 CCA
Alternator: 9 amp reg.
1,9 L (64 oz)
0,76 mm (0.030 in.)
20 Nm (180 in-lbs)
Intek Series 7220 OHV
TM
656 cc (40,03 cu in.)
Battery: 12 Volt, 190 CCA
Alternator: 9 amp reg.
1,9 L (64 oz)
0,76 mm (0.030 in.)
20 Nm (180 in-lbs)
Professional Series OHV
TM
724 cc (44,18 cu in.)
Battery: 12 Volt, 190 CCA
Alternator: 9 amp reg.
1,9 L (64 oz)
0,76 mm (0.030 in.)
20 Nm (180 in-lbs)
CHASSIS
Fuel Tank Capacity 6,0 L (1,5 gal)
Front Wheels Tire Size: 15 x 6.0
Inflation Pressure: 14 psi (0,96 bar)
Rear Wheels Tire Size: 20 x 8,0
Inflation Pressure: 10 psi (0,68 bar)
TRANSMISSION
Type Hydrostatic Hydro Gear
Engine Oil Synthetic 5W30
Speeds Forward: 0-9,0 km/h (0-5,6 mph)
Reverse: 0-4,5 km/h (0-2,8 mph)
@ 3400 rpm
Continuous Torque 233 Nm (172 ft-lbs)
Output
MOWER
Width of Cut 96,5 cm (38")
106,7 (42")
Number of Blades 2
Base Deck Platform Rear Discharge
Cutting Height 2,5-8,9 cm (1,0-3,5")
Cutting Positions 6
