Mowing
1. Set the mower cutting height to the desired level using
the mower lift lever.
2. Engage the parking brake. Make sure the PTO switch is
disengaged.
3. Start the engine (see Starting the Engine).
4. Set the throttle/choke control to the FAST position.
5. Engage the PTO to activate the mower blades.
6. Begin mowing.
NOTE: When the "catcher full" alarm sounds, turn off the
PTO immediately to prevent the discharge tube from plug-
ging. Travel to the desired location and empty the catcher
(see Emptying the Catcher).
7. When finished, shut off the PTO and raise the deck
using the mower lift lever.
8. Stop the engine (see Stopping the Tractor and
Engine).
Reverse Mowing Option (RMO
WARNING
Mowing in reverse can be hazardous to bystanders.
Tragic accidents can occur if the operator is not alert to the
presence of children. Never activate the RMO if children
are present. Children are often attracted to the unit and the
mowing activity.
The Reverse Mowing Option (RMO) allows the operator to
mow in reverse (see Features and Controls). To activate,
turn the RMO key after the PTO is engaged. The L.E.D. light
will illuminate, and the operator can then mow in reverse.
Each time the PTO is engaged the RMO needs to be
reactivated if desired. The key should be removed to restrict
access to the RMO.
22
Pushing the Tractor by Hand
1. Disengage the PTO and turn the engine off.
2. Pull the lever (A, Figure 6) toward the front of the unit
3. Pull up and push toward the rear of the unit to engage
Do not use another vehicle to push or pull this unit. Do not
actuate the transmission release lever while the engine is
running.

Parking Brake Function

Applying the Parking Brake - To lock the parking brake,
release the ground speed pedals (see Features and
Controls) fully depress the brake pedal, pull UP on the
parking brake knob, and then release brake pedal.
)
Releasing the Parking Brake - To release the parking
TM
brake, fully depress the brake pedal (see Features and
Controls) and push the parking brake knob (C) DOWN.

Cruise Control

TO ENGAGE:
1. Pull up on the cruise control knob (see Features and
2. Depress the forward ground speed pedal.
3. Lift up the cruise control knob when desired speed is
TO DISENGAGE:
1. Depress the brake pedal (see Features and
Controls).
OR
2. Depress the forward ground speed pedal.
and push down to lock in place. The tractor can now be
pushed by hand.
the transmission. The tractor can now be driven.
WARNING
Towing the unit will cause transmission damage.
Controls).
reached. The Cruise will lock in one of its five locking
positions.
