APPENDIX "B" - CHECKING PROXIMITY SENSOR IS WORKING
The check must take place, before connection to the electronic card, and then on assembly and
pointing on the front of the door.
APPENDIX "C" - CREATING A FILM EXECUTABLE IN FULL-HD
The 47" monitor has FULL-HD resolution 1920x1080.
To create a customised film, you need to follow the procedure indicated below.
IMPORTANT
The standard video, assembled as standard on the display, identifies the great possibilities of this
device.
Transparency between the product and the background of the tank, transparent and flashing panels to
indicate an advertised product, movement effects of the objects and much more.
Only by creating a correct background and adequate transparency, you can obtain the best of this
product.
Displaying a simple film without any transparency or effect will not give a good result.
Change the position of
the sensor, centring it
on the outer holes of the
door.
Sensor detection
area.
SETTING THE PROXIMITY SENSOR
