INFORMATION AND INSTRUCTIONS FOR THE OPERATOR
PRELIMINARY OPERATIONS
• Before inserting the plug, open the door and check the lights switch and video (2), on the display,
is in the "OFF" position.
• Inserting the plug, the refrigeration system only will start. It will be possible to adjust and check the
temperature using the commands on the grid (5-6).
• Now bring the switch (2) to the "ON" position. At this point the start-up procedure starts on the
monitor of the audio/video system. The process will last approximately 1 minute.
VIDEO CHECK
• Check the film starts with audio. IT is important to stand at least one metre away to avoid the film
blocking via the sensor positioned at the top front of the door. When the first viewing terminates,
the film with automatically re-start.
AUDIO CHECK
• The volume is pre-adjusted on the speakers placed on the motor chamber to 80% power. The speakers
are found in the motor chamber, but they can only be accessed by specialist staff. The volume is
adjustable using the two + / - keys behind the door (4). The software volume can be adjusted to a
minimum of -15 dB (off), and a maximum of +6 dB (max). The value is legible during adjustment,
directly on the monitor.
PRESENCE SENSOR CHECK
• The presence sensor (7), must detect presence at a distance of approximately 40-60 cm. Stand this
distance in front of the display and check the audio-video lock, the screen becomes transparent at
this point. Move away from the window and wait 5/6 seconds for the film to start again from the
beginning. If the system is not working, refer to appendix "B" of sensor control.
REPLACING THE DISPLAYED FILM
• The pen drive is situated behind the door, on the left, where you will see the "USB" (3) cover.
Remove the screws from the cover using a tool and remove the pen to replace the video. Carry out
the opposite procedure to re-assemble everything.
ATTENTION: The pen drive can only be removed and installed with the light switch and screen (2)
in the "OFF" position.
ATTENTION: The loadable video on the pen must be created following the directives indicated on
appendix "C" and must be called video.mp4.
