Montering af håndtag
Installation of lever
Montage von Hebel
Montage de manipulateur
C: Håndtaget skal skrues helt i bund
C: Screw the lever completely home
C: Den Hebel völlig einschrauben
C: Visser le manipulateur entierement au fond
Trykindstilling PVP, LS , LS
A
Pressure setting PVP, LS
Druckeinstellung PVP, LS
Réglage de pression PVP, LS
Relief valve 2
C-C
360º~120 bar
360º~1740 psi
T
Relief valve 1
Relief valve 2
© Danfoss A/S, 2015-05
B
, LS
A B
, LS
A B
, LS
A B
Relief valve 1
C-C
L S
360º~100 bar
360º~1450 psi
T
Before week 40/2003
x
520L0412 • Rev CE • May 2015
3 (1±0.15N•m)
LS B
C
C
LS A
C
C
PVP
C
T
P
Week 40/2003 - week 2/2004
x
x
8 ±1 N•m
V310 018_B
C
V310149.A
After week 2/2004
x
3
