Adjustable Charge Rates

12-Volt LiFePO Battery
4
Battery Capacity
Charge Rate
(Ah)
5 A 10 - 50
7 A 14 - 70
10 A 20 - 100
12 A 24 - 120
15 A 30 - 150
20 A 40 - 200
Charging Time
(Hours)
2 - 14
2 - 14
2 - 14
2 - 14
2 - 14
2 - 14
52

Fault Codes

Should an error occur, the LEDs on the device will light up and flash
in a number of ways to identify the possible cause of the fault:
= permanently lit, = flashing, — = off
● ☼
Power- Stage- Fault-
Error Code
LED LED LED
Reverse
Polarity / Out-
● — —
put Short
Non Battery
● — —
Link
Faulty Battery ● ☼ ●
Over Voltage ● — ●
Over Tempera-
● — ☼
ture
Cause Solution
Check clips are not
Short circuit or touching each other
reverse connection OR Check the clips
of the clips are correctly connect-
ed to the battery.
Please choose the
Non battery link right battery type for
connection.
Bulk charging has
Battery is faulty and
timed out and
may need to be re-
stopped after 24
placed.
hours.
The 12V battery Disconnect the charg-
voltage is above er and check the
17.5V. battery voltage. This
The 24V battery charger is suitable for
voltage is above 12V or 24V Batteries
35V. only.
Internal tempera-
Turn off charger and
ture is above 65OC
allow to cool.
+/-5OC
