2 Unpacking and assembling

2 Unpacking and assembling

2.1 Unpacking

2.2 Assembly

2
3
4
1
1. Unpack the appliance and all its accessories.
2. Check the contents for completeness and possible
damages. Information regarding scope of delivery
Page 22, "Overview of your Infinity V8".
NOTE:
Immediately contact your dealer if you have found
damage resulting from transportation.
ATTENTION:
Always transport or ship the appliance in its original
packaging to avoid damage. Keep the packaging for
such an event.
Dispose of no longer needed packaging material
according to the applicable regulations of your country.
WARNING:
Danger of injury! Only assemble the appliance if it is not
connected to the power supply. Otherwise the machine
might start up and parts of your body, hair or pieces of
clothing might be sucked in.
1. Insert the end of the vacuum hose with the notch
topside into the socket. Turn the end of the suction hose
clockwise until the lock clicks audibly and noticeably
into place (Fig. 2).
2. Insert the handle (Fig. 3/1) into the upper end of the
telescopic tube (Fig. 3/2) until it snaps into place.
3. Attach the floor nozzle (Fig. 3/3) to the bottom end of
the telescopic tube (Fig. 3/4).
NOTE:
It might be necessary to push a bit harder.
4. Adjust the length of the telescopic tube. Press down the
release latch on the tube (Fig. 4/1) to do this. Then
extend the telescopic tube to the desired length. Let go
of the release catch while pulling until it locks in place.
You will hear a distinct click.
Your cylinder vacuum cleaner is now ready for use.
27
