Permanent Wiring to Battery

It is possible to hard wire the DC charging leads to the battery for
permanent installations. You will need 2 x ring terminals, an inline
fuse holder and a fuse with a rating equal to or more than twice of
the chargers output.
4 A = 8 Amp fuse
5 A = 10 Amp fuse
7 A = 15 Amp fuse
10 A = 20 Amp fuse
Connection:
1. Cut off the supplied battery clips; ensure you leave sufficient
cable to reach the battery terminals. (DO NOT extend the bat-
tery charger DC cables, as the added voltage drop will cause
incorrect charging).
2. Fit a ring terminal to the BLACK Negative (-) wire.
3. Connect the inline fuse to the RED Positive (+) wire.
4. Connect a ring terminal to the other end of the inline fuse.
5. Connect the RED lead (with inline fuse and ring terminal) to
the Positive (+) battery post.
6. Connect the BLACK lead (with ring terminal) to the Negative
(-) battery post.
7. Fit the correctly rated fuse.
12 A = 25 Amp fuse
15 A = 30 Amp fuse
20 A = 40 Amp fuse
