Charging Instructions
Negatively earthed (most vehicles)
Connect the RED lead (battery clip) from the charger to the Posi-
tive (+) battery terminal. Connect the BLACK lead (battery clip)
from the charger to the vehicle's chassis away from the fuel line
or moving parts.
Positively earthed
Connect the BLACK lead (battery clip) from the charger to the
Negative (-) battery terminal. Connect the RED lead (battery clip)
from the charger to the vehicle's chassis away from the fuel line or
moving parts.
F A N
F A N
50
Black
Red
Connection inside
vehicle (negatively earthed)
Black
Connection inside
vehicle (positively earthed)
Red
