Installation and connection of the appliance / Technical details
Important
During installation, the power cable position must be taken
account in. Avoid the temperature to be above 50ć at any
point of the power cable. The oven complies with safety
standards set by the regulatory bodies. The oven is safe to
use only if it has been adequately earthed in compliance with
current legal requirements on wiring safety. You must ensure
that the oven has been adequately earthed.
The manufacturers cannot be held responsible for any
harm or injury to persons, animals or belongings caused
by failure to properly earth the oven.
Connection of the hob
The hob to work with 230V alternating current, electrical
connection must get the power from the oven. Remember
that the connection should match the same colour , here is
Black – Black, White-White, Blue-Blue, Green-Green.
Insert the plug located at the end of the hob's cable bund-
le into the respective sockets on the oven switch panel.

Technical details

Supplier's name
Model
Oven model
Hob model
Hob model name
Power 1
Voltage 1
Power 2
Voltage 2
Oven model name
Supplier's name
Energy efficiency index (EEI
Energy class
Energy consumption per cycle in
forced air mode
Energy consumption per cycle in con-
ventional mode
Number of cavities
Heat source per cavity
Volume of each cavity
KKT KOLBE
SET6010ED
EH6010ED
EM592ED
EM592ED
6000-7200 W
220–240 V~
6600 W
400V 3N~
EH6010ED
KKT KOLBE
) 94
cavity
A
0.79 KWh/cycle
0.99 KWh/cycle
1
Electricity
70 L
