1. Low pressure
connector 1/4" SAE
2. High pressure
connector 1/4" SAE
3. Refrigerant / vacuum
connector 1/4" SAE
4. Low pressure valve
(blue)
5. High pressure valve
(red)
6. K-type socket
7. Hook
8. Micro USB connector
9. SD card connector
10. Vacuum connector
3/8" SAE
11. Refrigerant connector
1/4" SAE
12. Vacuum valve (yellow)
13. Refrigerant valve
(black)
Bedienungsanleitung REFMATE
To connect a hose
To connect a hose
To connect a hose
Turn to the left to open or turn
clockwise to close
Turn to the left to open or turn
clockwise to close
Socket for temperature sensor or
temperature clamp
To hang the device
Slot for micro USB cable to connect to
a computer
SD card slot
To connect a hose
To connect a hose
Turn to the left to open or turn
clockwise to close
Turn to the left to open or turn
clockwise to close
