Turbo-V 903 Pumping System User Manual / 87-901-016-01
Procedure to Connect the Serial and I/O ports to an External Cable
W L
R/W L
R/W L
R/W N
R/W N
Reserved to Agilent service
Reserved to Agilent service
R N
R N
R N
R N
R N
R N
R N
R N
R N
Technical Information
Pump life/ cycle time/ cycle
number reset
Interlock type
(default = 1)
Analog output type: output
voltage signal pro-portional
to frequency or power
Rotational frequency setting
(Hz)
Maximum rotational
frequency in Hz (active only
in Stop condition)
Pump current in mA dc
Pump voltage in Vdc
Pump power in W (pump
current x pump voltage duty
cycle)
Driving frequency in Hz
Pump temperature in °C
Pump status
Error code
Cycle time in minutes
(zeroed by the reset
command)
Cycle number (zeroed by the
reset command)
(A)
18
To reset write
'1'
Impulse = 0
Continuous = 1
0 = frequency
1 = power
(default = 0)
150 to 1100'
(default = 1100)
150 to 1100
(default = 1100)
Stop = 0
Waiting intlk = 1
Starting = 2
Auto-tuning = 3
Braking = 4
Normal = 5
Fail = 6
Bit description:
see the
following figure
0 to 999999
0 to 9999
