GB
8.2 Switching on (Fig. 3)
Notes:
The hot air generator can be connected to any
n
shock-proof socket with 230 V AC and a 10 A
circuit-breaker. We recommend that you connect
the machine only to a power supply which is
protected by means of an earth-leakage circuit
breaker (RCD) with a maximum trip current of 30
mA.
Please only use power cables that are not
n
damaged. There is a limit to how long power
cables can be (max. 50m). The power cable must
have a cross-section of 3 x 1.5 mm².
We recommend that you go outdoors to start up
n
the equipment for the first time (this will take
approx. 10 minutes) so that any oil residues
remaining on the sheet metal parts after
production can be burnt off.
1. Connect the power plug to an extension cable.
2. Use the thermostat knob (Item 14) to set the
desired temperature (range + 5 °C to + 45 °C).
3. Set the ON/OFF switch (Item 13) to position ON
(I) – the equipment will start, the LED (Item 15)
will light up and the room temperature will be
indicated (Item 5).
Notes:
The temperature indicator works only in the range
n
from 0 °C to + 99 °C. At temperatures below 0°C
the indicator will show "LO", at temperatures
above + 99 °C it will show "HI".
If the firing does not switch on, the thermostat
n
must be adjusted to a higher temperature. If,
contrary to expectations, the heating still fails to
switch on, switch off the equipment and check it
against the error list (section 12)
8.3 Switching off
1. Set the ON/OFF switch (Fig. 3/Item 13) to the
OFF (0) position – the equipment will switch off.
2. Pull out the power plug.
8.4 Switching on again
1. Wait at least 10 seconds before switching on
again.
2. Switch on the equipment again as described in
8.2 and follow all the previous notes.

9. Replacing the power cable

If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
18
10. Cleaning, maintenance and
ordering of spare parts
Always pull out the power plug before starting any
cleaning work.
10.1 Cleaning
Keep all safety devices, air vents and the motor
n
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
down with compressed air at low pressure.
We recommend that you clean the equipment
n
immediately after you use it.
Clean the equipment regularly with a damp cloth
n
and some soft soap.
Do not use cleaning agents or solvents; these
may be aggressive to the plastic parts in the
equipment. Ensure that no water can get into the
interior of the equipment.
10.2 At the end of the season and before long
breaks in operation (Fig. 4)
Empty the fuel tank via the drain plug (9) on the
bottom of the tank by pulling the plug cover in
downwards direction.
If the drain plug is damaged, be sure to replace it.
Press the new plug into the tank drain hole and close
it with the plug cover (see Fig. 5).
Store the equipment and accessories out of children's
reach in a dark and dry place at above freezing
temperature. The ideal storage temperature is
between 5 und 30 °C.
10.3 Servicing
Servicing work may be carried out only by specially
trained personnel. Please contact Customer Service.
10.4 Ordering replacement parts:
Please provide the following information on all orders
for spare parts:
Equipment model/type
n
Equipment article number
n
Equipment ID number
n
Spare part number of the required spare part
n
For our latest prices and information please go to
www.isc-gmbh.info
