17
Technical Information
Water Cooling Kit Installation
The items of the plastic model kit must be assembled as shown in the following
CAUTION!
figure
Figure 28
The assembled kit must be screwed into the suitable holes of the
pump body with a recommended closing torque of 5 Nm. The metallic
model is assembled as shown in the figure.
Figure 29
240/264
TV 401/301 MS User Manual / 87-901-013-01
(A)
