Green mode (AM detectors only)
The detector can be programmed in several ways to minimize
the human and animal exposure to microwave radiation,
although the detector is already sending microwave signal on a
very low power level.
The detector will switch the microwave section off for 3 minutes
after a dual alarm. The detector is in PIR only during this timer.
Settings option 1 J1: Off
Settings option 2 J1: Removed
The microwave section is switched off and for DD66XAM is
switched to AM section. The detector operates in PIR mode
only.
Setting J1: Removed

LED indication

DD66X
Dual
Start up
Low voltage
(Dual) motion
intruder alarm
Latched PIR
(Memory)
DD66XAM
Dual / AM
Start up Closed
Low voltage Open
(Alarm)
(Dual) motion Open
intruder alarm (Alarm)
Latched PIR
(Memory)
AM alarm Open
(Alarm) [2]
Technical fault
Continuously on Normal blinking (1 Hz)
[1] Tri-colour LED.
[2] Depends on the setting of the DIP switch SW8.

Specifications

DD669 DD666-D DD669AM
Detector
Range diameter
or 12 ±0.5 m (39 ft. 4 in. ±1 ft. 7 in.)
(selectable)
Viewing angle
(selectable)
P/N 146249999-5 (ML) • REV G • ISS 28FEB19
System in Armed status
System in Disarmed status
System Walk Test Disabled
Closed Automatically after 45 s
Open Apply correct voltage
(Alarm)
Open Automatically after 3 s
(Alarm)
Switch to Night mode
Closed Automatically after
60 s
Open Apply correct voltage
(Alarm)
Automatically after 3 s
Switch to Night mode
Open See DIP switch 7
(Alarm)
Open Pass walk test
(Alarm)
DD666AM-D
Dual Dual + AM
20 ±0.5 m (65 ft. 7 in. ±1 ft. 7 in.)
360 degrees or 180 degrees
DD669 DD666-D DD669AM
Optical
Microwave
frequency
Maximum power
output
Max microwave
output at 1 m
Memory
Input power
Peak-to-peak ripple
Detector start-up
time
Normal current 12 mA
consumption
Current consumption 10 mA
in Alarm
Maximum current 15 mA
consumption
Mounting height 2.5 to 5.0 m (8 ft. 2 in. to 16 ft. 5 in.)
Target speed range 0.3 to
3.0 m/s
(1 ft./s
to 9 ft.
10 in./s)
Alarm (NC) / Tamper 80 mA
relay characteristic 30 VDC
Form A
Pry off tamper Optional
AM relay
characteristic
Alarm time
Operating
temperature
 138 x 92 mm ( 5.43 in. x 3.62 in.)
Dimensions ( x H)
Relative humidity
Weight
IP/IK rating

Regulatory information

Manufacturer UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings THESE PRODUCTS ARE INTENDED FOR SALE
TO AND INSTALLATION BY QUALIFIED
and disclaimers
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED
DEALER" OR "AUTHORIZED RESELLER", IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/
Certification
DD666AM-D
2 x 9 curtains
5725 to 5875 MHz
3.89 W
0.003 μW/cm²
Yes
9 to 15 VDC (12 V nominal)
2 V (at 12 VDC)
45 s 60 s
19 mA
20 mA
25 mA
0.2 to 0.2 to 0.2 to 3.0 m/s
3.0 m/s 3.0 m/s (8 in./s to 9 ft.
(8 in./s to (8 in./s to
9 ft. 9 ft. 10 in./s)
10 in./s)
80 mA 80 mA
30 VDC 30 VDC
Form C Form A
On board (Yes)
N/A 80 mA at 30 VDC max.
3 s
−10 to +55°C (14 to 130°F)
max. 95%
255 g (9 oz.)
IP30 IK04
or scan the QR code.
10 in./s)
80 mA
30 VDC
Form C
5 / 40
