CVM-C10
DESCRIPTION
Scheinleistung L3
Dreiphasige Scheinleis-
tung
Spitzenbedarf I1
Spitzenbedarf I2
Spitzenbedarf I3
Spitzenbedarf A
Spitzenbedarf kW
Spitzenbedarf kVA
Analog Value Object Type
1. Dynamically creatable using BACnet's CreateObject service?
2. Dynamically deleatable using BACnet's DeleteObject service?
3. List of optional properties supported:
4. List of all properties that are writable where not otherwise required by this standard
5. List of propietary properties:
Property Identifier
5. List of object identifiers and their meaning in this device
Object ID
AV1
AV2
AV3
Device Object Type
1. Dynamically creatable using BACnet's CreateObject service?
2. Dynamically deleatable using BACnet's DeleteObject service? No
3. List of optional properties supported:
4. List of all properties that are writable where not otherwise required by this standard
Object_Name
Max_Master
Max_Info_Frames
Object_Identifier
5. List of propietary properties:
5. List of any property value range restrictions
Property Identifier
Object_Name
Object_Identifier
Number_Of_APDU_Retries
APDU_Timeout
Vendor_Identifier
Data Link Layer Options (check all that supported):
X
MS/TP master (Clause 9), baud rate(s): 9.6, 19.2kB/s
Character Sets Supported (check all that apply):
Indicating support for multiple character set does not imply that they can all be supported simulta-
neously.
X
ANSI X3.4
Betriebsanleitung
Aparent power L3
Three phase aparent
power
Maximum demand I1
Maximum demand I2
Maximum demand I3
Maximum demand A
Maximum demand kW
Maximum demand kVA
Property Datatype
Object Name
MAC_Address
BaudRate
Device_ID
Restrictions
< 7 bytes
Device Type only
0-255
0-65535 miliseconds
0-65535
SYMBOL
ID OBJECTS OBJECT NAME
kVA
AI42
kVAIII
AI43
Md (A1)
AI44
Md(A2)
AI45
Md(A3)
AI46
A III
AI47
kW III
AI48
kVA III
AI49
No
No
No
Description, Protocolo_Conformance_Class
UNITS
AppPwrPh3
AppPw3Ph
MaxDemand_A1
MaxDemand_A2
MaxDemand_A3
MaxDemand_A
MaxDemand_kW
MaxDemand_
kVA
Meaning
Description
MAC
BAUD RATE
DEVICE ID
kVA
kVA
A
A
A
A
kW
kVA
77
