输出模式开关设置
图例：F = 关闭，O = 开启
DVI 模式
指标
0 720x487/59.94P
1 720x576/50.00P
2 1280X720/23.98P
3 1280X720/24.00P
4 1280X720/25.00P
5 1280X720/29.97P
6 1280X720/30.00P
7 1280x720/50.00P
8 1280x720/59.94P
9 1280x720/60.00P
10 1920x1080/50.00P
11 1920x1080/59.94P
12 1920x1080/60.00P
13 1920x1080/23.98P
14 1920x1080/24.00P
15 1920x1080/25.00P
16 1920x1080/29.97P
17 1920x1080/30.00P
18 1920x1080/50.00P
19 1920x1080/59.94P
20 1920x1080/60.00P
21 640x480/60 VGA
22 640x480/75 VGA
23 640x480/85.01 VGA
24 800x600/60.32 SVGA
25 800x600/75 SVGA
26 800x600/85.06 SVGA
27 1024x768/60 XGA
28 1024x768/75.03 XGA
29 1024x768/85 XGA
30 1152x864/70.01 XGA
31 1152x864/75 XGA
32 1152x864/85 XGA
33 1280x768/59.87 WXGA
34 1280x960/60 SXGA
35 1280x960/75 SXGA
36 1280x960/85 SXGA
37 1280x1024/60.02 SXGA
38 1280x1024/75.02 SXGA
39 1280x1024/85.02 SXGA
40 1360X768/60.01WXGA
41 1366X768/59.79 WXGA
42 1440X900/59.89 WXGA
43 1600X1200/60 UXGA
44 1680X1050/59.95 WSXGA
45 1920x1200/50 WUXGA
46 1920x1200/60 WUXGA
47
用户菜单
* 注：若要从 ScaleOR的
模式
SDI 模式
720x480/59.94I
720x576/50.00I
1280X720/23.98P
1280X720/24.00P
1280X720/25.00P
1280X720/29.97P
1280X720/30.00P
1280x720/50.00P
1280x720/59.94P
1280x720/60.00P
1920x1080/50.00I
1920x1080/59.94I
1920x1080/60.00I
1920x1080/23.98P
1920x1080/24.00P
1920x1080/25.00P
1920x1080/29.97P
1920x1080/30.00P
1920x1080/50.00P
1920x1080/59.94P
1920x1080/60.00P
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
不适用
*
OSM
设置输出模式，必须将所有的开关设为关闭。
DIP 开关
6 5 4
O O O
O O O
O O O
O O O
O O O
O O O
O O O
O O O
O O F
O O F
O O F
O O F
O O F
O O F
O O F
O O F
O F O
O F O
O F O
O F O
O F O
O F O
O F O
O F O
O F F
O F F
O F F
O F F
O F F
O F F
O F F
O F F
F O O
F O O
F O O
F O O
F O O
F O O
F O O
F O O
F O F
F O F
F O F
F O F
F O F
F O F
F O F
F F F
3 2 1
O O O
O O F
O F O
O F F
F O O
F O F
F F O
F F F
O O O
O O F
O F O
O F F
F O O
F O F
F F O
F F F
O O O
O O F
O F O
O F F
F O O
F O F
F F O
F F F
O O O
O O F
O F O
O F F
F O O
F O F
F F O
F F F
O O O
O O F
O F O
O F F
F O O
F O F
F F O
F F F
O O O
O O F
O F O
O F F
F O O
F O F
F F O
F F F
