1
2
3
4
5
6
7
1

External measurement

2

Internal measurement

inch/mm ON/OFF
10
11
12
ZERO
MetricMaster Plus
1 Measuring jaws for
external measurement
8
2
Switch between
in and mm
3 On/Off switch
4 Zeroing the
digital display
9
5 Fine adjustment wheel
6 Scale 0 ... 150 mm
7 Depth gauge
8 Measuring jaws for
internal measurement
9
LC display
10
Clamping screw for
fixing the measured
value
11
Measurement in
in / mm
12 Battery compartment
3
Depth measurement
inch/mm ON/OFF ZERO
MetricMaster Plus
EN
07
