Delete the last measured value:
Change measurement point (reference):
2 sec
The device starts up with the last setting.
Measuring plane, pin/stop:
For measurements out of a corner,
fold down the pin and select the
„measurement plane PIN" setting.

Length measurement:

device on
1x
18
EN
front thread
1x
1x
laser on
2x
rear (stop)
2x
For stop measurements move the pin
to the side and select the „measure-
ment plane REAR" setting.
measurement
3x
pin
3x
