Function list on the receiver in Muting mode (LED 3 ON Yellow)
Function
Coding
Muting/Blanking selection
EDM 2
Reset function
Muting direction
Muting timeout
Override trigger
1
The default configuration (at delivery) is indicated in bold characters.
2 th
Please look at the 4 LED, and not the one called "EDM".
2TLC172296M0201 Rev A
2015-03-20
LED
1
Setting
number
Code 1
2 Code 2
No Code
Muting
3
Blanking
Enabled
4
Disabled
Auto
5
Manual
T/X (bidirectional)
6
L (monodirectional)
10 min
7
Infinite
Level
8
Edge
9
LED Status
LEVEL
1 2 3 4 5 6 7 8
