Function list on the receiver in Blanking mode (LED 3 OFF)
Function
Coding
Muting/Blanking selection
EDM 2
Reset function
Floating blanking selection
Fixed blanking selection
1
The default configuration (at delivery) is indicated in bold characters.
2 th
Please look at the 4 LED, and not the one called "EDM".
2TLC172296M0201 Rev A
2015-03-20
LED
1
Setting
number
Code 1
2 Code 2
No Code
Muting
3
Blanking
Enabled
4
Disabled
Auto
5
Manual
Floating blanking disabled
Floating blanking 1 beam
6-7
Floating blanking 2 beams
Reduced Res. 4 beams
1 Fixed blanking zone
8
2 Fixed blanking zones
10
LED Status
LEVEL
1 2 3 4 5 6 7 8
