EuroLite AKKU IP UP-4 Plus Bedienungsanleitung Seite 26

Jump/Fade
000 - 255
Red – 125 - 255
Green – 125 - 255
Blue – 125 - 255
White Bal
White – 125 - 255
Amber – 125 - 255
UV – 125 - 255
Temperat
xxC
Sys Info
Cur Power
xxx%
Economy ON/OFF
Dis Perm ON/OFF
Def.Set YES/NO
Wireless Setting
This device is prepared for wireless data transmission (WDMX) ex works. If you wish to de-activate WDMX
control, you can select the function "Power" – "Off". With the function "Power" – "On" you can log in the
wireless receiver to a wireless transmitter, the fixture could now receive the wireless DMX signal.
With the function "Unlink", you can log out the projector from the wireless sender.
Progr 7 Red Dark
Progr 8 Red Green
Progr 9 Red Blue
Progr 10 Red Amber
Progr 11 Red Yellow
Progr 12 Red Cyan
Progr 13 Red Magenta
Progr 14 Red White
Progr 15 Green Dark
Progr 16 Green Blue
Progr 17 Green Amber
Progr 18 Green Yellow
Progr 19 Green Cyan
Progr 20 Green Magenta
Progr 21 Green White
Progr 22 Blue Dark
Progr 23 Blue Amber
Progr 24 Blue Yellow
Progr 25 Blue Cyan
Progr 26 Blue Magenta
Jump (000 – 255)
Switching colors with increasing speed;
Fade (000 – 255)
Fading colors with increasing speed
White balance
Default setting: RGBWA+UV = 125
Internal temperature of the device
Remaining battery power in percent
Power-save mode
ON - power save mode, 50 % power
OFF - full power
Display shutoff
ON - display does not shut off
OFF- Shuts off the display after 30 seconds
Press any button for 3 seconds to release the lock.
Reset to factory settings
26/32
Progr 33 Yellow Dark
Progr 34 Yellow Cyan
Progr 35 Yellow Magenta
Progr 36 Yellow White
Progr 37 Cyan Dark
Progr 38 Cyan Magenta
Progr 39 Cyan White
Progr 40 Magenta Dark
Progr 41 Magenta White
Progr 42 White Dark
Progr 43 UV Dark
Progr 44 UV Red
Progr 45 UV Green
Progr 46 UV Blue
Progr 47 UV Amber
Progr 48 UV Yellow
Progr 49 UV Cyan
Progr 50 UV Magenta
Progr 51 UV White
00124275, Version 1.0
