TECHNICAL FEATURES

• Structure and coating in grey-painted steel.
• Internal firebox in Vermiculite.
• Ash grate in cast iron and ash pan.
A
• Internal firebox width 25 cm, height 38 cm.
B
• Self-closing door.
• Primary combustion air adjustment.
Obtained by moving the lever A (illustration 1):
- push inwards to open.
- push outwards to close.
fig. 1 - Adjustment lever
Primary air is used to manage flame intensity.
• Secondary combustion air adjustment.
Obtained by moving the lever B (illustration 1):
right open - left closed.
Secondary air not only enables the ceramic glass to be cleaned,
it also enables the combustion of any gases that could develop
from incomplete combustion of the wood, thereby reducing the
risk of hazardous gases entering the room. The preset amount of
secondary air enters the firebox through a passage in the door's
upper glass retainer.
DIMENSIONS
Ø 15
40
9
