BML-S1G0-_7_ _-M5EG-_0-_ _
Absolute magnetic encoder system
11
Type code
S = Sensor head
Style/housing geometry (W x H x L):
G = 16 × 18.5 × 80 mm
Interface:
B = BiSS C (bi-directional serial synchronous), absolute
S = SSI (serial synchronous), absolute
m = Mitsubishi interface
Operating voltage:
7 = 5 VDC, 10...28 VDC
Data format:
B, M interface
E = Binary increasing
S interface
(bits incl. error and null bit)
24 bits
0 = Binary, rising 6 = Binary, rising
1 = Gray, rising 7 = Gray, rising
2 = Binary, falling 8 = Binary, falling
3 = Gray, falling 9 = Gray, falling
Resolution:
C = 0.9765625 µm
(1000/1024 µm) per LSB
Pole width:
5 = 2 mm
Magnetic tape coding
Incremental real-time signal:
G = Analog real-time sin/cos (1 Vpp) signal for functional safety
Min. edge separation/period:
Analog real-time signal
D = Analog sin/cos (1Vpp), period 2 mm
Connection technology/special versions:
S284 = Axial plug with pin contacts, M12A-12-pin
KA05 = PU cable, standard, 5 m cable, possible cable lengths 0.5; 2; 5 m
Ordering example (also applies to rotary applications):
BML-S1G0-S7AD-M5EG-D0-S284
34 english
25 bits 26 bits
A = Binary, rising
B = Gray, rising
C = Binary, falling
D = Gray, falling
D = 1 µm per LSB
E = 2 µm per LSB
BML - S1G0 - S71D - M5EG - D0 - S284
32 bits
E = Binary, rising
F = Gray, rising
G = Binary, falling
H = Gray, falling
F = 5 µm per LSB
G = 10 µm per LSB
