Instructions
1 - Introduction
These instructions pertain to the Maneurop®
MT, MTZ & NTZ compressors used for refrigera-
tion systems. They provide necessary informa-
tion regarding safety and proper usage of this
product.
2 – Handling and storage
• H andle the compressor with care. Use the
dedicated handles in the packaging. Use the
compressor lifting lug and use appropriate
and safe lifting equipment.
• S tore and transport the compressor in an
upright position.
• S tore the compressor between -35°C and
50°C.
• D on't expose the compressor and the packa-
ging to rain or corrosive atmosphere.
3 – Safety measures before assembly
Never use the compressor in a flammable
atmosphere.
• T he compressor ambient temperature may
not exceed 50°C during off-cycle.
• M ount the compressor on a horizontal flat
surface with less than 3° slope.
• V erify that the power supply corresponds to
the compressor motor characteristics (see
nameplate).
• W hen installing MTZ or NTZ, use equipment
specifically reserved for HFC refrigerants
which was never used for CFC refrigerants.
• U se clean and dehydrated refrigeration-
grade copper tubes and silver alloy brazing
material.
• U se clean and dehydrated system components.
• T he piping connected to the compressor must
be flexible in 3 dimensions to dampen vibrations.
4 - Assembly
• S lowly release the nitrogen holding charge
through the schrader port.
• R emove the gaskets when brazing rotolock
connectors.
• A lways use new gaskets for assembly.
• C onnect the compressor to the system as
soon as possible to avoid oil contamination
from ambient moisture.
• A void material entering into the system while
cutting tubes. Never drill holes where burrs
cannot be removed.
• B raze with great care using state-of-the-art tech-
nique and vent piping with nitrogen gas flow.
• C onnect the required safety and control de-
vices. When the schrader port is used for this,
remove the internal valve.
5 – Leak detection
Never pressurize the circuit with oxygen or
dry air. This could cause fire or explosion.
• D o not use dye for leak detection.
• P erform a leak detection test on the complete
system.
• T he low side test pressure must not exceed 25
bar.
• W hen a leak is discovered, repair the leak and
repeat the leak detection.
6 – Vacuum dehydration
• N ever use the compressor to evacuate the
system.
• C onnect a vacuum pump to both the LP & HP
sides.
• E vacuate the system to a pressure of 500 µm
Hg (0.67 mbar) absolute.
