User Manual
This program is only suitable for charging Pb lead-acid battery with
nominal voltage from 6 to 12V, Pb lead-acid battery is a completely
different from NiMH/NiCD battery. These batteries can only deliver
current lower in comparison to their capacity. The same restriction
applies to the charging process consquently, the optimum charge
current can only be 1/10 of the capacity. Pb battery can not be used
for fast-charging. Please follow the instructions provided by the
battery manufacturer.
CHARGING OF PB BATTERY
-
+
DEC. INC.
Batt type
Start
Stop
Enter
Pb-6 4.0A 14.40V
CHG 022:43 001300
Elapse d
Batter y
Batter y
voltag e
time
typ e
Charge
curren t
DISCHARGING OF PB BATTERY
-
+
.
DEC. INC
DEC. INC.
Batt type
Start
Stop
Enter
www.modster.at
Set up the charge current on the left and
nominal voltage on the right. Range of
current 0.1-6.0A, the voltage should match
-
+
the battery being charged. Press START/
DEC. INC.
ENTER button for more than 3 seconds to
>3 seconds
start charging.
The screen display the real-time charging
status. Press START/ENTER button again
to store the parameter value you set. Press
BATT TYPE/STOP button to end the
Charge d
program.
capacit y
Set up the discharge current on the left and
nominal voltage on the right. Range of
discharge current is 0.1-2.0A, the voltage
-
+
should match the battery being discharged.
Press ENTER/START button for more than
>3 seconds
3 seconds to start discharging.
MODSTER Charger 60
47
