Modster CHARGER 60 Betriebsanleitung Seite 43

User Manual
LITHIUM BATTERY(LiPo/LiFe/LiIon/LiHV)PROGRAM
Start
Enter
Number
Elapsed
of
time
cells
Charging
current
CHARGING OF LITHIUM BATTERY
This charging mode is for charging LiPo/LiFe/LiIon/LiHV battery in
normal mode. Note: We recommend charging lithium batteries with a
balance lead in the balance mode only.
-
+
DEC. INC.
Batt type Start
Stop Enter
www.modster.at
This screen displays the number of cells
you set up and the processor detects.
R=Number of cells detected by charger.
S=Number of cells set by you at the
previous screen.
If both numbers are identical you can start
charging process. If not, press BATT TYPE/
STOP button to go back to previous screen
to recheck the number of cells of the
battery pack before going ahead.
This screen shows the real-time status
Battery
Charged
voltage
capacity
during charge process. Press BATT TYPE/
STOP button once to stop the charge
process.
The left side of the first line shows the type
of battery you choose. The value on the left
of the second line of the charger is current
the user sets. After setting the current and
-
+
voltage, press the START/ENTER button for
DEC. INC.
more than 3 seconds to start the process.
>3 seconds
This displays the number of cells you set
up and the processor detects.
R=Number of cells detected by charger.
S=Number of cells set by you at the
previous screen.
MODSTER Charger 60
43
