User Manual
• Do not allow water, moisture, metal wires or other conductive
material into the charger. Never charge or discharge any bettery
having evidence of leaking, expansion/swelling. Damaged outer
cover or case, color-change or distortion.
• Do not try to charge "non-rechargeable" dry cells.
• Do not exceed the bettery manufacturer's suggested maximum
charge rates.
• Carefully follow the battery pack manufacturer's recommendations
and safety advice.
Please bear in mind the following points before commencing
charging
• Did you select the appropriate program suitable for the type of
battery you are charging?
• Did you set up appropriate current for charging or discharging?
• Have you checked the battery voltage? Lithium battery packs can
be wired in parallel and in series, i.e. a 2-cell pack can be 3.7V (in
W A R N I N G A N D S A F E T Y N O T E S
parallel) or 7.4V (in series).
• Have you checked that all connections are firm and secure? Make
sure there are no intermittent contacts at any point in the circuit.
Standard Battery Parameters
Nominal
Voltage
Max Charge
Voltage
Storage
Voltage
Allowable
Fast Charge
Min. Discharge
Voltage
www.modster.at
LiIon
LiFe
LiPo
3.7V/cell
3.6V/cell
3.3V/cell
4.2V/cell
4.1V/cell
3.6V/cell
3.8V/cell
3.7V/cell
3.3V/cell
1C
1C
3.0-3.3V/cell2 .9-3.2V/cell2 .6-2.9V/cell
MODSTER Charger 60
LiHV
NiCd
3.8V/cell
1.2V/cell
4.35V/cell
1.5V/cell
3.90V/cell
n/a
4C
1C
1C-2C
0.1-1.1V/cell0 .1-1.1V/cell 1.8V/cell
3.1-3.4V/cell
NiMH
Pb
1.2V/cell
2.0V/cell
1.5V/cell
2.46V/cell
n/a
n/a
1C-2C
0.4C
31
