 If the device is not going to be used for a prolonged period the
batteries should be removed.
WARNING: The measurement results given by this device
is not a diagnosis. It is not replacing the need for the consul-
tation of a physician, especially if not matching the patient's
symptoms. Do not rely on the measurement result only,
always consider other potentially occurring symptoms and
the patient's feedback. Calling a doctor or an ambulance is
advised if needed.

3. How this Thermometer measures Temperature

This thermometer measures infrared energy radiated from the
forehead as well as objects. This energy is collected through the
lens and converted to a temperature value.

4. Control Displays and Symbols

 All segments displayed 9: Press the START/IO button 7 to
turn on the unit; all segments will be shown for 1 second.
 Ready for measuring AT: When the unit is ready for measuring,
the «°C» or «°F» icon will keep flashing while the mode icon
(body or object) will be displayed.
 Measuring countdown BR: A 3 second countdown will be
shown on the display (3, 2, 1), before each measurement.
 Measurement complete AK: The reading will be shown on the
display 4 with the «°C» or «°F» icon and the mode icon
steady. The unit is ready for the next measurement as soon as
the «°C» or «°F» icon is flashing again.
 Low battery indicator AN: When the unit is turned on, the
«battery» icon will keep flashing to remind the user to replace the
batteries.

5. Setting Date, Time and Beeper Functions

Setting the date and time
1. After the new batteries are fitted, the year number flashes in the
display BO. You can set the year by pressing the M-button 5.
To confirm and then set the month, press the MODE button 6.
2. Press the M-button 5 to set the month. Press the MODE
button 6 to confirm and then set the day.
3. Follow the previously mentioned instructions to set the day,
hours and minutes.
4. Once you have set the minutes and pressed the START/IO
button 7, the date and time are set and the time is displayed.
4

If no button is pressed for 20 seconds, the device automat-
ically switches to ready for measuring AT.

Cancel time setup: Press the START/IO button 7 during
time setup. The LCD will show Date/Time icons with «--:--».
After that press the START/IO button 7 to start the
measurement. If no further action is taken within 30
seconds, the device will automatically turn off.

Change current date and time: Press and hold the MODE
button 6 for approx. 8 seconds until the year number
starts to flash BO. Now you can enter the new values as
described above.
Setting the beeper
1. Press and hold the MODE button 6 for 3 seconds to set the
beeper BP.
2. Press the M-button 5 to either turn the beeper on or off. The
beeper is activated when the beeper icon BP is shown without
a cross.

When the beeper setting has been chosen, press the
START/IO button 7 to enter the «ready for measuring»
mode; otherwise the device automatically switches to ready
for measuring after 10 seconds AT.

6. Changing between Body and Object Mode

1. Press the START/IO button 7. The display 4 is activated to
show all segments for 1 second.
2. The default mode is body mode. Press the MODE button 6 to
switch to object mode. For switching back to body mode, press
the MODE button again.

7. Directions for Use

Always remove the protective cap BS before use.
Measuring in body mode with auto measurement and
distance control
1. Press the START/IO button 7. The display 4 is activated to
show all segments for 1 second.
2. A flashing «°C»/«°F» icon, the blinking blue tracking light 2 and
a beep indicate that the device is ready for measurement AT.
3. Remove any hair, sweat or dirt from the forehead before
measuring to ensure the accuracy of the readings.
4. Aim the thermometer at the center of the forehead with a
distance of no more than 5 cm.
