LF313T
Measurement
conditions
Storage
conditions
Characteristic data
on delivery
Pin assignment
ba75522e04
11/2015
Conductivity measuring
range
Temperature range
Max. allowed overpressure
Minumum depth of immer-
sion
Maximum depth of immer-
sion
Operating position
Recommended storing
method
Storage temperature
Temperature responding
behavior
Precision of the temperature
sensor
NTC
30 k
0.001 µS/cm ... 200 µS/cm
-5 ... 80 °C (100 °C)
5
2 x 10
Pa (2 bar)
30 mm
Entire sensor+cable (up to 80 °C)
Sensor shaft only (=120 mm / up to 100 °C)
any
in air
0 ... 50 °C
t
(99 % of the final value after) < 20 s
99
± 0.2 K
8
NTC
6
not used
1
NTC
4
4
Outer electrode
2
2
5
5
Inner electrode
3
3
7
Shield
Plug from the front:
5
7
Technical data
2
4
1
8
3
6
7
