Technical data
General features
Dimensions
(in mm)
Weight
Materials
Connection cable
Pressure
resistance
6
4
Technical data
Measuring principle
Cell constant
Temperature sensor
120.0
12.0
approx. 135 g
Shaft
Connection head
Conductivity electrodes
Thermistor enclosure
Lengths
Diameter
Smallest allowed
bend radius
Plug type
Sensor with closed plug
connection
Cable plug
The LF313T meets the requirements according to article 3(3) of the
97/23/EC directive ("Pressure equipment directive").
Two-electrode measurement
-1
0.100 cm
±2 %
integrated NTC 30 (30 kΩ/ 25 °C)
165
Stainless steel 1.4571
POM
Stainless steel 1.4571
Stainless steel 1.4571
1,5 m
6 mm
Permanent bend:
Single time or short time bend:
Socket, 8 pins
IP 68 (2 x 10
IP 67 (when plugged in)
17.5
5
Pa or 2 bar)
ba75522e04
LF313T
80 mm
50 mm
11/2015
