Emos ZU1110.12 Handbuch Seite 2

1
2
Model Voltage Frequency
ZU1110.12 100-277V 50/60Hz
ZU1110.9 100-277V 50/60Hz
ZU1110.6 100-277V 50/60Hz
ZU1115.12 100-277V 50/60Hz
ZU1115.9 100-277V 50/60Hz
ZU1115.6 100-277V 50/60Hz
ZU1120.12 100-277V 50/60Hz
ZU1120.9 100-277V 50/60Hz
ZU1120.6 100-277V 50/60Hz
CCT Wattage PF Lumen
4000K 100W ≥0.9 15000lm
4000K 100W ≥0.9 15000lm
4000K 100W ≥0.9 15000lm
4000K 150W ≥0.9 22500lm
4000K 150W ≥0.9 22500lm
4000K 150W ≥0.9 22500lm
4000K 200W ≥0.9 30000lm
4000K 200W ≥0.9 30000lm
4000K 200W ≥0.9 30000lm
2
Beam
Dimension IP Humidity
Angle
120° D255*H162mm IP65
90° D255*H162mm IP65
60° D255*H162mm IP65
120° D255*H162mm IP65
90° D255*H162mm IP65
60° D255*H162mm IP65
120° D400*H190mm IP65
90° D400*H190mm IP65
60° D400*H190mm IP65
Working
Weight
Temperature
10-90% -40~40°C 2.40kg
10-90% -40~40°C 2.40kg
10-90% -40~40°C 2.40kg
10-90% -40~40°C 2.65kg
10-90% -40~40°C 2.65kg
10-90% -40~40°C 2.65kg
10-90% -40~40°C 5.30kg
10-90% -40~40°C 5.30kg
10-90% -40~40°C 5.30kg
