The fastening holes found at the base coin-
cide with the standard electric boxes on the
market.
In the case the connecting cable does not
come from the electric box, the thermostat
must be fastened to the wall with the an-
chors and screws supplied.
Keep in mind that the rectangular hole in
the centre of the base is to house the elec-
tric connecting cable.
Standard electric connections,
thermostat DPC-1R
stat with relays)
Once the base is fastened to the wall, wire
the thermostat as shown in the following il-
lustration:
Data and measurements are subject to change without prior notice.
14
Caution
mostat and the control board. Connections
to be carried out are R, B, G, Y, Y2, O/B, W
and AL. (Phase "R" of the alarm relay).
To connect the remote sensor use screened
2 x 0.5 mm
100 m. between the thermostat and the sen-
sor. The connections to be carried out are
RS1 and RS2.
(for thermo-
A screened 10 x 0.22 mm² cable,
with a maximum length of 100 m.,
should be used between the ther-
2
cable with a maximum length of
GB
To connect the digital remtoe probe use
2
screened 3 x 0.5 mm cable, with a maxi-
mum length of 100m, between the thermo-
stat and the kast probe. Connections to be
mode R, B and X1.
For correct operation of the thermostat, it is
indispensable to have made electric wiring
properly, and have inserted the two AAA 1.5
V alkaline batteries at the rear of the front
panel, as shown below:
