Product Safety Information; Product Specifications - Ingersoll-Rand 41AA6LTH4-EU Technische Produktdaten

Product Safety Information

Intended Use:
These tools are designed to install or remove threaded fasteners.
For Additional information refer to Air Screwdriver Product Safety Information Manual
Form 04585006.
Manuals can be downloaded from www.ingersollrandproducts.com

Product Specifications

Model
41AA6LTH4-EU Auto shut off
41AA6LTS6-EU Auto shut off
41AA9LTS6-EU Auto shut off
Installation and Lubrication
Size air supply line to ensure tool's maximum operating pressure (PMAX) at tool inlet. Drain
condensate from valve(s) at low point(s) of piping, air filter and compressor tank daily. Install
a properly sized Safety Air Fuse upstream of hose and use an anti-whip device across any
hose coupling without internal shut-off, to prevent hose whipping if a hose fails or coupling
disconnects. See drawing 16585820 and table on page 2. Maintenance frequency is shown in a
circular arrow and defined as h=hours, d=days, and m=months of actual use. Items identified as:
1. Air filter
2. Regulator
3. Lubricator
4. Emergency shut-off valve
5. Hose diameter
6. Thread size
Clutch Adjustment
External
1. Rotate the External Adjustment Sleeve until opening in Housing is visible.
2. Rotate drive Spindle of Right Angle Housing until notch in Adjustment Washer is visible.
3. Insert No.1 Philips screwdriver in notch to turn gear teeth on Adjustment Nut.
4. Turning clockwise will decrease torque.
5. Turning counterclockwise will increase torque.
80167372_ed2
Drive
Clutch
Type
Type
Hex
Square
Square
Free Sound Level dB (A)
Speed ANSI S5.1-1971
size rpm Pressure
1/4" 600
3/8" 600
3/8" 900
7. Coupling
8. Safety Air Fuse
9. Oil
10. Grease - through fitting
11. Grease - disassembly required
EN
Vibration
Level
(ISO28927)
m/s²
77.0 < 2.5
77.0 < 2.5
77.0 < 2.5
EN-1
