Drill stand
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
Familiarise yourself with the product before using
it for the first time. In addition, please carefully re-
fer to the operating instructions and the safety ad-
vice below. Only use the product as instructed and
only for the indicated field of application. Keep
these instructions in a safe place. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.

Intended use

The product is designed for commercial drills and is
suitable for placing exactly defined holes at right-an-
gles into wood, metal and ceramic tiles. It is possi-
ble to mount the work-piece securely during drilling.
Consult the manufacturer's operating manual be-
fore using the drill. The product is not intended for
commercial use.

Parts description

Drill stand:
Bolt
1
Lever arm
2
Drill holding fixture
3
Guide slot (4 x)
4
Drill hole (4 x)
5
Base plate
6
Pillar
7
Block
8
Slider
9
Locking knob
10
Drill depth gauge with indicator
11
Screw
12
Vise:
Vise
13
Long slot
14
14 GB/MT
Locking device
15
Quick-release button
16
Clamping jaw
17
Contents
1 Drill stand
1 Hexagon key
1 Vise
1 Operating instructions
Technical data
Drill holding fixture for
clamping collar diameter: 43 mm
Drilling depth:
Dimensions:
Clamping jaw width:
Clamp width:

Safety advice

YOU SHOULD STORE ALL SAFETY INFORMA-
TION AND INSTRUCTIONS IN A SAFE PLACE
IN CASE YOU NEED TO REFER TO THEM AGAIN
IN THE FUTURE!
CAUTION! RISK OF INJURY! When
working with hand-operated electrical tool,
slipping or loosening of the mounted work-
piece can cause severe injuries. Therefore,
never work on a mounted work-piece using
a hand-operated electrical tool.
CAUTION! RISK OF SHEARING OR
CRUSHING INJURY! There is the risk of
shearing or crushing injuries while working
with the drill stand.
CAUTION! RISK OF INJURY! Pay atten-
tion to flying chippings and splinters. There
is the risk of injury.
to 60 mm steplessly
adjustable
155 x 505 x 225 mm
(W x H x D)
65 mm
65 mm
