Option B
Figure 10
Finally, check that the clamping sheet is securely attached to
the gas cylinder base and that the swivel plates are engaged.
Supporting feet
Due to the restricted space with some common gas cylinder
types, the gas cylinder must be placed on supporting feet (8)
in order to protect the Truma LevelControl against damage.
Have supporting feet installed by an expert only. Installation
in vehicles must comply with the technical and administrative
regulations of the respective country of use (e.g. EN 1949).
Figure 11

LevelControl magnetic foil.

So that the Truma LevelControl is not forgotten about on the gas
cylinder when the gas cylinder is replaced, fit the LevelControl
magnetic foil in a clearly visible location on the gas cylinder.
Figure 12
Secure the LevelControl magnetic foil to aluminium gas
cylinders with LevelControl strap .

Replacing a gas cylinder

Caution – risk of crush injury! Carefully lift and set down
gas cylinders.
Every time a gas cylinder is replaced, the gas cylinder
base and the Truma LevelControl, particularly the cou-
pling pad (1), must be cleaned to remove snow, ice, rust or
dirt (see "Cleaning").
Do not pull the Truma LevelControl along the gas cylin-
der base, as this can damage the coupling pad (1).
Carefully set down the gas cylinder in order to avoid
8
damage to the Truma LevelControl.
