to the following connection diagrams.
Ensure that all connections are fastened secu-
rely to the installation terminals.
•
Wire the DIN rail modules for the bus power supply
(terminals 1.4 and 1.8) with the power supply.
Make sure that the connections are made with
correct polarity on the terminals.
Note that actual buttons (normally open) and
no rocker switches or push-button switches are
used in the button input circuits. Connect each
of the buttons between GND (terminal 1.8) and
the respective button input (terminal 2.4 or 2.8).
The maximum wire length from button to modu-
le is different depending on the wire used.
A length of 50 m should never be exceeded
however.
Permitted wire cross-section for connecting to the ac-
tuators.
Rigid wire [mm
0.14 – 2.50
]
2
Flexible wire with end
sleeve [mm
0.14 – 1.5
]
2
