Make sure that the specified wiring and wire cross-
sections are used when connecting to device ter-
minals.
Switch actuator:
Follow all technical specifications, especially the ma-
ximum permitted switching capacity of the relay and
type of consumer to be connected, before connecting
the consumer! All load specifications refer to resistive
loads!
Shutter actuator:
The actuator is only suitable for 230 V a.c. motors!
Never connect three-phase a.c. motors or d.c. motors!
If motors are connected to the output in parallel
with the actuator, make sure to observe the motor
manufacturer's specifications. The motors can be da-
maged otherwise.
Use only blinds or shutters with limit switch (mechani-
cal or electronic)!
Check the limit switch for the connected motors for
proper adjustment before starting the shutter actuator!
Dimming actuator:
Make sure to observe the applied load!
