Fitting the Truck Mounted Charger System
Electrical Connection
The electric connection of the truck mounted charger system may only be performed by qualified
personnel.
Otherwise the device or the vehicle could get damaged.
The truck charger system is supplied by the on-board vehicle power network. If the vehicle is to
be parked for more than 12 hours without additional power supply, the charger system could dis-
charge the vehicle battery. Therefore, MSA recommends installing an additional circuit breaker
in case the power supply is solely provided by the on-board battery.
It is recommended that the power supply be taken directly from the vehicle power source and that
no other devices be connected to this power line. Power surges caused by other electrical devices
on the same line may cause the charger fuse to blow.
(1) Connect positive line (red) in series with fuse and circuit breaker.
(2) Connect circuit breaker with ignition power or voltage source.
(3) Connect earthing cable (black) to the vehicle chassis ground.
8
NOTICE
NOTICE
