MSA EVOLUTION 5600 Kurzanleitung

Quick Start Guide
EVOLUTION
Thermal Imaging Camera
4
A Front view of the camera
B On-screen indicators
1 Battery compartment lock
2 Camera handle
3 ON / OFF button
4 Display
5 Shutter indicator
GB
Downloaded from www.Manualslib.com
®
The quick start guide does not replace the operating
manual. It is imperative that the operating manual be
read and observed when using the thermal imaging
camera. In particular, the safety instructions, as well as
the information for the use and operation of the
apparatus, must be carefully read and observed.
The operating manual can also be provided as a hard
copy upon request.
3
2
1
manuals search engine
5600
A
5
6
7
8
6 Target point of the temperature
indicator
7 Low sensitivity mode "L"
8 Over temperature Indicator
9 System status
10 Battery status indicators
11 Numerical temperature indicator
12 Graphic temperature indicator
B
12
11
9 10
Order No.: 10084447/00
