E N G L I S H

RTE84H ROTARYORBITAL SANDER

1. TECHNICAL DATA

Universal Motor.................................50/60 Hz
Power...................................................180 W
Adjustable speed..............7,000-12,500/min
Stroks.....................................14000-25000
Orbit diameter.........................................2 mm
Abrasive disk diameter..........................D.125
Weight..................................................1.4 Kg
Weighted equivalent continuous
acoustic pressure level A....................................76 dBA
Uncertainty......................................................K = 3 dBA
Wear ear protection!
Vibration total values...............................a
Uncertainty.....................................................K: 1.5 m/s
2. USES
The single-handed rotaryorbital sanding machine
RTE84H combines two types of movement, rotary
and orbital, enabling it to perform planing and
finish work very quickly. The smooth, sanded
groove-free surfaces it produces make it ideal for
delicate jobs and vernished wood.
The electronic speed adjustment feature allows
you to work at the ideal speed for each surface
and abrasive type which is particularly useful for
sanding heat-sensitive materials requiring lower
sanding speeds.
To achieve the desired finish, the surface should
be sanded several times using a finer grain of
abrasive each time. The sander is equipped with a
plate for abrasive disks which are secured by velcro
and a device for forced aspiration of sanding dust.

3. STANDARD EQUIPMENT

Inside the box you will find the following:
- Electronic rotaryorbital sander RTE84H
- Dust collection bag set
- Instruction manual and other documentation
- 1 Velcro abrasive disk
4. OPTIONAL ACCESSORIES
- 6446073 Standard dust collection attachment.
To connect the machine to an external suctioning
source.
5. SAFETY INSTRUCTIONS
FOR HANDLING THE MACHINE
-1
1. The voltage must correspond to the data indi-
cated on the feature plate.
2. Danger! Keep hands away from working area.
Do not hold the machine from underneath while
it is running.
: 3.8 m/s
2
3. It is advisable to use only original VIRUTEX
h
2
abrasives.
4. Inspect wood and remove any nails before
sanding.
5. Never use the sanding machine in the presence
of liquids or excessive humidity.
6. Never leave an electric tool before all moving
parts have come to a complete stop.
7. The dust that accumulates during the sanding
process may prove to be toxic or harmful to the
health (for example, in the case of lead-based
paints, certain woods or metals). Use the dust
collector connection at all times.
8. REPLACEMENT PARTS: Use only original repla-
cement parts.
6. STARTING THE MACHINE AND
ELECTRONIC ADJUSTMENT
To start the machine, move switch "B" to the right.
To adjust the speed, turn button "A" to the desired
working speed (Fig. 1).
Before using any the sander, carefully
read the GENERAL SAFETY INSTRUC-
TION BROCHURE which is included
with the machine documentation.
