Product Safety Information; Product Specifications - Ingersoll-Rand 5LL2D6-EU Technische Produktdaten

Product Safety Information

Intended Use:
These tools are designed to install or remove threaded fasteners.
For additional information refer to Product Safety Information Manual Form 04585006.
Manuals can be downloaded from ingersollrandproducts.com

Product Specifications

Model
5LL2D6-EU Non Reversible Lever
5RLK2D6-EU Non Reversible Lever
5RLL2D6-EU Non Reversible Lever
5RLN2D6-EU Non Reversible Lever
5RLK2C5-EU
5RLL2C5-EU
5RLN2C6-EU
5RLK2C3-EU
5RLL2C3-EU
5RLN2C3-EU
Model Free Speed
5LL2D6-EU
5RLK2D6-EU
5RLL2D6-EU
5RLN2D6-EU
5RLK2C5-EU
5RLL2C5-EU
5RLN2C6-EU
5RLK2C3-EU
5RLL2C3-EU
5RLN2C3-EU
† K = 3dB measurement uncertainty
pA
Sound and vibration values were measured in compliance with internationally recognized
test standards. The exposure to the user in a specific tool application may vary from these
results. Therefore, on site measurements should be used to determine the hazard level in
that specific application.
80167489_ed3
Style
Reversible Lever
Reversible Lever
Reversible Lever
Reversible Lever
Reversible Lever
Reversible Lever
Torque Range
(soft draw)
in-lbs (Nm)
1,500 60 (6.8)
1,800 40 (4.6)
1,300 55 (6.3)
600 110 (12.5)
1,800 10-40 (1.1-4.6)
1,300 15-55 (1.7-6.3)
600 15-110 (1.7-12.4)
1,800 10-40 (1.1-4.6)
700 15-55 (1.7-6.3)
600 15-110 (1.7-12.4)
WARNING
Clutch
Type
Stall
Stall
Stall
Stall
Adjustable Cushion
Adjustable Cushion
Adjustable Cushion
Adjustable Cushion
Adjustable Cushion
Adjustable Cushion
Sound Level dB(A)
(ISO15744)
† Pressure (L
74.6
74.6
74.6
74.6
71.4
71.4
71.4
71.4
71.4
71.4
EN
Drive
Type Size
Square 3/8"
Square 3/8"
Square 3/8"
Square 3/8"
Square 1/4"
Square 1/4"
Square 3/8"
Hex Shank Bit 1/4"
Hex Shank Bit 1/4"
Hex Shank Bit 1/4"
Vibration Level
(ISO28927)
) m/s²
p
< 2.5
< 2.5
< 2.5
< 2.5
< 2.5
< 2.5
< 2.5
< 2.5
< 2.5
< 2.5
EN-1
