ELECTRICAL CONNECTION
WARNING THIS APPLIANCE MUST BE EARTHED
Assembly and Positioning
FITTING THE CASTORS
WARNING The radiator must only be operated with the
wheels and castors fitted and in the upright position.
The castors must be fitted to the control panel and on the
bracketbetweenthelastandsecondlastfinontheopposite
end, as shown in Fig.1.
Tofitthecastors,turntheradiatorupsidedownonacarpetor
other soft surface to avoid damage
Warning : The radiator is heavy – ensure that it is supported
to prevent it from toppling. Ask a second person to help with
this if necessary.
Tofitthecastors,positionthecastorplates(A)inpositionand
secure using the wing bolts (B). there are guides to ensure the
correct positioning and orientation of the caster plate.
Return the radiator to the correct orientation so it rests on the
castors. The product is now ready for use.
POSITIONING THE HEATER
Select the position for the heater ensuring there is clearance
fromanyfurnitureandfittingsofatleast300mmabovethe
heater and 150mm each side and 300mm from the control and
end panel. We recommend maximising the clearance where
possible.
Models & General Information
MODELS
Model Description
5fin,thermostat,threeheatsettings&
ECO15
Neon
5fin,thermostat,threeheatsettings,neon
ECO15C2A
& electro mechanical timer
5fin,thermostat,threeheatsettings,neon
ECO15C2B
& electronic 7 day timer
7fin,thermostat,threeheatsettings&
ECO20
Neon
7fin,thermostat,threeheatsettings,neon
ECO20C2A
& electro mechanical timer
7fin,thermostat,threeheatsettings,neon
ECO20C2B
& electronic 7 day timer
11fin,thermostat,threeheatsettings&
ECO25
Neon
11fin,thermostat,threeheatsettings,neon
ECO25C2A
& electro mechanical timer
11fin,thermostat,threeheatsettings,neon
ECO25C2B
& electronic 7 day timer
GENERAL
The radiator is designed for operation on an AC electricity
supply, and is suitable for use in domestic dwellings and similar
indoor locations.
The radiator is fitted with castors and a handle for ease of
movement. A rotary selector switch provide the ability to
chooseanavailableheatoutputandanadjustablethermostat
enables the room temperature to be controlled accordingly. It
is supplied with a cord and plug and is ready for use once the
castorshavebeencorrectlyfitted.
IMPORTANT - OBJECTS OR CLOTHING MUST NOT BE
PLACED ON THIS HEATER.
Before using the heater ensure that all warnings and instructions
have been read carefully.
Once the castors have been fitted, to activate the heater
simply plug it in. Neon indicating lights (i, see Fig 2) located at
the controls area will illuminate when the appliance is plugged
into the mains. This indicates the appliance is energised and
ready for use.
CONTROLS (See Fig. 2 & 3)
Thermostat (T)
The Thermostat controls the heat output according to the room
temperature. This ensures that the heater will not produce heat
unnecessarily when the room is warm. To set the temperature
you require, turn the thermostat knob clockwise until the
requiredsettingisreached.Alternativelytoheatacoldroom
quickly,turnthethermostatknobupfully.Whentheroomhas
reached the desired temperature, turn the thermostat knob
anti-clockwiseuntilthethermostatjustclicksoff.Theheaterwill
now automatically operate at this temperature. The thermostat
also has a frost protection setting marked '
useful in areas such as garages, to prevent frost damage. If the
Power
thermostat is set to its minimum setting '
(W)
cycleonandofftomaintainatemperatureofapproximately
5° to help protect against frost.
1500
Note – Should the heater fail to come on when the thermostat
is at a low setting, this may be due to the room temperature
1500
being higher than the thermostat setting.
1500
Heat Selector Switch (S)
Heat selection is provided via a rotary switch offering four
2000
settings. The heat output can be altered to suit the application,
conditions and for improve the economy of operation.
2000
Available output options are as follows:
2000
2500
Model
ECO15(C2*)
2500
ECO20(C2*)
2500
ECO25(C2*)

Operation

',theheaterwill
Switch setting
O I II
Off 500W 1000W
Off 600W 1400W
Off 800W 1700W
'. This setting is
III
1500W
2000W
2500W
