Contents
System description ................................
Dimensions and clearances ..................
Installation material ...............................
Accessories ..........................................
Installation ............................................
Refrigerant connections ........................

System description

System description (See fig. 1)
R. Outdoor unit
S. Indoor unit
T. Remote Control (if foreseen)
1 Automatic swinging louvre
2 Air return
3 Air filters
4 Air outlet
5 Remote control signal receiver
6 Unit operating status indicators
7 Unit nameplate
8 Interconnecting tubing
9 Condensate drain
Indoor unit display (See fig. 2)
 Blue light: illuminated during Ionizer activated
 Orange light: illuminated during timer mode.
 Green light: illuminated during operation.
TEST operation:
Is exclusively used by service personnel to test unit

Dimensions and clearances

Unit dimensions references (mm) are shown in fig. 4
42XPP A
1080
050 - 070
1460
100
1 42XPP
Page
1
1
2
2
2 - 3
3
B C
295 200
340 240
Electrical connection .............................
Installing remote control bracket ............
Maintenance .........................................
Guide for the owner ...............................
Useful info .............................................
operation.
The test procedure is activated via the remote control.
EmERgEnCy Button (See fig. 3)
Can be used when the remote control is lost or
inoperative.
d Emergency Button
Emergency operation:
When the unit is in the OFF mode and the T button is
pressed for 5 seconds, the unit will operate as follows:
• Automatic mode
• Temperature preset to 22°C (050, 070) or 25°C (100)
• Automatic fan speed
• Louvres set automatically according to the operating
mode
• OFF timer
When a signal is received by the remote control, the unit
operates accordingly.
Minimum installation clearances references are (mm)
shown in fig. 6
X
14 300 450
23 300 450
Hi-Wall
Page
y Z W
120 2000
120 2000
4
4
4 - 5
5
5
