Overview of components
WB 2
1
1 Upper housing section
comprising flash
shrouds, PCB and flash
tubes
Flash shroud colours:
red, yellow, orange,
green, blue, clear, white
2 Housing base
3 M20x1,5 cable entry
4 Terminals
a) DC version
b) AC version
Assembly and connection
1. Screw the housing base
in place.
2. Place the connecting
cable on the terminal.
Ensure correct polarity
on DC units!
3. Close the cable entry.
4. Place the upper housing
section in place and
screw in place.
5. Check that the unit
functions properly.
