CAUTION
Risk of flying objects!
If the umbrella comes loose and flies around, it could cause uncontrolled damage,
damage to property or injuries.
• Do not use the umbrella in windy conditions.
• Always ensure that the device is stable.
• Never leave the device unattended.

Transporting and attaching the anti-glare shields

The anti-glare shield can be attached to
the Profi HD for transport. Attach the
inner magnets of the anti-glare shield to
the two lower magnets of the Profi HD.
The anti-glare protection is fitted under
the cover of the Profi HD. Slide the anti-
glare shield into the hinge slots (1) of
the cover. Magnets provide additional
support.
In order to achieve the best possible
effekt, you must place the anti-glare
protection over the tab. Loosen the
wing nut (2) so that the cover and the
anti-glare shield can move freely.
