Cable drum

Connect a reel/ cable drum or an adapter to Profi HD

Connect the 6-pin plug of the reel/cable
drum or of the adapter to the 6-pin socket
of the base unit. Make sure that the plug is
positioned correctly. For this purpose, the red
dot on the plug has to be aligned with the red
dot on the socket.
TIP Before you start working, check whether the reel or the cable drum is analog or
digital. For analog reels or cable drums an adapter is needed.
