Locking brake

To prevent the device from moving unintentionally, apply the locking brake lever. If you want
to push the device, release the locking brake lever.
Press the brake lever down to lock the
brake and up to release it.

Monitor cover

The cover protects the monitor and
most of the controls on the tab.
Open the cover by turning the wing nut
forward. Grasp the cover in the middle
and move it to the desired position.
Turn the wing nut backwards to fix
the cover. If the cover is fully raised or
lowered, the wing nut does not need to
be tightened.

Removing and inserting the Tab

EasyTab or proTab is required to operate the Profi HD. The respective tab is inserted into the
Profi HD.
To insert the Tab, hold it on both sides
with both hands. Pull the purple latches
on the back with your fingers outwards.
Insert the Tab and make sure that it
snaps into the corresponding slots.
Slide the latches back slowly. Check
that the Tab is securely attached before
releasing it.
