Chicco oasys i-Size Gebrauchsanleitung Seite 23

ZE
taneously in height to 6 different positions
R'S
using button X to follow your child's growth.
4. Overlap the two ends of the harness straps,
ro- insert them together inside the buckle until
you hear them clicking (Fig. 21)
WARNING! Never insert just one end of the
ed
harness into the buckle or insert them one at a
n it time. Press button Q to adjust the straps.
ori- 5. Tighten the child car seat's safety harness by
he pulling the adjustment strap (Fig. 22).
WARNING! The reducer cushion guarantees
ad the correct support and the ideal position for
he the neck and back of babies from when they
7) are born until they weigh about 6 kg.
ag-
3.2 USE AS RECLINED CRADLE
ed
When the child car seat is not used in a car, it
out can be used as a reclined cradle.
not Place on stable horizontal surfaces only.
WARNING! Before carrying the child car seat,
18). always move the carry handle to position B
(vertical).
WARNING! Do not leave the child unattended.
he
WARNING! Always use the restraint system.
WARNING! Using the child car seat on raised
n B
surfaces such as tables, chairs etc. can be dan-
nd gerous.
WARNING! This child car seat is not designed
for long periods of sleep.
WARNING! Do not use the seat when the
LD
child is able to sit up independently.
TY
This child car seat is not a replacement for a
bed or crib. Should your child need to sleep,
ol- place your child in a suitable bed or cot. Do
not use the child car seat if any part is broken
he or missing.
em
3.3 USE WITH THE STROLLER
he The Oasys i-Size child car seat can only be used
with LOVE UP - StyleGo UP strollers.
WARNING! Please read the Stroller instruction
ays manual when using the child car seat on the
wth stroller.
in- Before fastening the child car seat, remove the
to stroller seat.
he To install the child car seat on the stroller, pro-
ck- ceed as follows:
he - Hold the child car seat with the handle in the
ul- vertical position (B) (Fig. 23).
- Fit the connecting points (U) into the slots
on the stroller (Fig. 24A – LOVE UP, Fig. 24B –
StyleGo UP ). Pay particular attention that the
seat is engaged on both sides. You will hear a
CLICK when it is fastened correctly.
WARNING: Before use, make sure that all the
child car seat fastening devices are correctly
engaged.
To remove the child car seat from the stroller:
1. Put the carry handle into vertical position (B).
2. Pull first the rear release handle (W), then lift
the child car seat by the handle (Fig. 25A -
LOVE UP, Fig. 25B - StyleGo UP).
WARNING! The child car seat can be fastened
and unfastened with the baby inside; these
procedures could be more difficult due to the
weight of the baby. Be very careful when per-
forming the steps described above.
3.4 CANOPY
The car seat features a protective canopy that
can be adjusted to multiple positions.
To fit it, insert the ends of the canopy in the
relevant fastening devices (Fig. 26) and then
fit the elastic strap through the relevant hooks
(Fig. 27). Fasten the buttons on the back of the
canopy to complete fitting (Fig. 28).
3.5 CLEANING AND STORAGE
HOW TO CLEAN THE PLASTIC AND METAL
PARTS
Clean the plastic and coated metal parts with a
damp cloth only. Never use abrasive detergents
or solvents.
The movable parts of the child Car seat must
not be lubricated.
CLEANING THE FABRIC LINING
The child seat's fabric lining can be removed
and washed by hand or in a washing machine
at 30°C.
To wash it, unfasten the straps, remove the
shoulder straps by opening the snap-buttons
located inside the compartment for storing
the instruction manual (Fig. 29) and pull off
from the straps (Fig. 30). Then remove the
straps from the slots and the lining from the
headrest (Fig. 31). Remove the fabric lining
from the seat starting from the feet posi-
23
